POWER
Guide No. (ISO100).meters
60 (200mm)
ZOOM
Zoom head
Yes
Focal length coverage
20-200mm
Coverage with wide panel
14mm
Auto zoom for sensor size
Yes
FLASH MODES
Auto exposure control
E-TTLII/E-TTL/TTL
High speed sync (FP)
Yes
Manual / output settings
Yes - 1/1-1/128
Manual steps
1/3 step
Strobe / output settings
Yes - 1/4-1/128
Frequency
1-199Hz
FLASH-RELATED FUNCTION
FE lock
Yes
Flash exposure compensation
Yes
Flash exposure bracketing
Yes
Second-curtain flash sync
Yes
Modelling flash
Yes
Colour temperature info communication
Yes
WIRELESS FLASH
Transmitter
Yes
Transmission type
Infra-red
Transmitter Max range approx.
Indoors: 12-15m
Outdoors: 8-10m
Slave
Yes
No. of groups
3¹
No. of channels
4
FLASH HEAD MOVEMENT
Up
45, 60, 75 and 90 °
Down
7 °
Left
60, 75, 90, 120, 150 and 180 °
Right
60, 75, 90, 120, 150 and 180 °
AF ASSIST
AF-assist beam
Yes
Number of AF points supported
1 - 61
AF-assist beam type
Infra-red
POWER SOURCE
Battery
4 x AA batteries
Minimum recycling time*
Approx. 3.3 sec
External power supply
Yes - CP-E4
CONSTRUCTION
Dust and water resistance
Yes
Mounting foot material
Metal
MISC.
Custom function
18 (5 personal functions)
Flash settings from camera menus**
Yes
External flash exposure sensor
Yes
PC terminal
Yes
Compatible accessories
Off-camera shoe cord OC-E3
Compact battery Pack CP-E4
EX Series Speedlite with Slave function
Color filter holder SCH-E1
Color filter SCF-E1
Dedicated flash bracket
SB-E2
DIMENSIONS & WEIGHT
Size (W x H x D), mm
79.7x 142.9x 125.4¹
Weight (Excluding batteries), grams
425g
Одрекување од одговорност
* Time taken to recharge flash after full discharge using Alkaline AA batteries.
** With Compatible cameras only.
Фуснота
¹ As default only flash in group C are triggered wireless, set C.Fn 5-1 to wirelessly trigger groups A & B
¹ Except for the dust and water prevention adaptor
